CFL Double Turn DE Type • Dimmable • 13W • 3500K • G24q-1 4-Pin

New 2021 Energy Rating: G

Energy Labelling Guide

Dimmable compact fluorescent double turn DE-Type lamp (PLC-E).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads, pendants and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

Stock Code: CLDE13SW

Related Products

Dimmable compact fluorescent double turn DE-Type lamp (PLC-E).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads, pendants and other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • G24q-1 4-Pin cap
  • 3500K white colour temperature
  • Colour rendering index ≥85
  • Suitable for dimming
  • Recommended for indoor use only
  • 2 year warranty

Part Code:

CLDE13SW

Product Name:

CFL Double Turn DE Type 13W Dimmable 3500K G24q-1 4 Pin

Notes:

Suitable for use in emergency luminaires. Separate ballast/control gear required.

Nominal Wattage:

13W

Nominal Luminous Flux:

900lm

Nominal Life:

10,000 hours

Dimmable:

Dimmable

Cap Type:

G24q-1 4-Pin

Energy Saving:

No

Energy Efficiency Class:

New 2021 Energy Rating: G

Pre-2021: A

Rated Wattage (0.1W Precision):

13.0W

Power Factor λ:

>0.94

Weighted Energy Consumption:

15W

Rated Total Luminous Flux:

900lm

Colour Temperature:

3500K

Colour Name:

White

Weighted Energy Consumption:

COL835

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

≥80%

Efficiency:

69lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Diameter:

41mm

Height:

131mm

Product Weight:

0.04kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986523357

Single Carton Length:

3.5cm

Single Carton Width:

3.5cm

Single Carton Height:

15cm

Single Carton Volume:

183.75cm³

Single Carton Weight:

0.053KG

Inner Carton GS1-128 Barcode:

02050189865233573750

Inner Carton Quantity:

50

Inner Carton Length:

18.5cm

Inner Carton Width:

36.5cm

Inner Carton Height:

16cm

Inner Carton Volume:

10804cm³

Inner Carton Weight:

2.861kg

Outer Carton GS1-128 Barcode:

020501898652335737200

Outer Carton Quantity:

200

Outer Carton Length:

38.5cm

Outer Carton Width:

39cm

Outer Carton Height:

34.5cm

Outer Carton Volume:

51801.75cm³
