CFL Single Turn L Type • Dimmable • 40W • 3500K • 2G11

New 2021 Energy Rating: G

Energy Labelling Guide

Dimmable compact fluorescent single turn L-Type lamp (PLL).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and many other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

Stock Code: CLL40SW

Related Products

Dimmable compact fluorescent single turn L-Type lamp (PLL).

Commonly used in commercial and domestic luminaires. Ideal for use in downlights, bulkheads and many other suitable applications.

Spectra-Plus Triphosphor coated for excellent colour rendering, high output and long life.

Suitable for dimming and use in emergency luminaires.

Separate ballast/control gear required.

  • 10,000 hour life
  • 8,000 switching cycles
  • 2G11 cap
  • 3500K white colour temperature
  • Colour rendering index ≥85
  • Suitable for dimming
  • Recommended for indoor use only
  • 2 year warranty

Part Code:

CLL40SW

Product Name:

CFL Single Turn L Type 40W Dimmable 3500K 2G11

Notes:

Suitable for use in emergency luminaires. Separate ballast/control gear required.

Nominal Wattage:

40W

Nominal Luminous Flux:

3320lm

Nominal Life:

10,000 hours

Dimmable:

Dimmable

Cap Type:

2G11

Energy Saving:

No

Energy Efficiency Class:

New 2021 Energy Rating: G

Pre-2021: A

Rated Wattage (0.1W Precision):

40.0W

Power Factor λ:

>0.98

Weighted Energy Consumption:

43W

Rated Total Luminous Flux:

3320lm

Colour Temperature:

3500K

Colour Name:

White

Weighted Energy Consumption:

COL835

Colour Rendering Index:

≥85

Starting Time:

10 seconds

Warm Up Time (to 60% Light Output):

<60 seconds

Lumen Maintenance Factor:

≥81%

Efficiency:

83lm/W

Rated Life:

10,000 hours

Switching Cycles:

8,000

Warranty:

2 years

Diameter:

44mm

Height:

536mm

Product Weight:

0.128kg

Mercury (Hg) Content:

2.5mg

EAN13 Barcode:

5018986522954

Single Carton Length:

4.5cm

Single Carton Width:

2.5cm

Single Carton Height:

54.6cm

Single Carton Volume:

614.25cm³

Single Carton Weight:

0.162KG

Inner Carton GS1-128 Barcode:

02050189865229543710

Inner Carton Quantity:

10

Inner Carton Length:

10cm

Inner Carton Width:

14cm

Inner Carton Height:

56.5cm

Inner Carton Volume:

7910cm³

Inner Carton Weight:

1.778kg

Outer Carton GS1-128 Barcode:

02050189865229543750

Outer Carton Quantity:

50

Outer Carton Length:

53cm

Outer Carton Width:

58.5cm

Outer Carton Height:

16cm

Outer Carton Volume:

49608cm³
