- 50,000 hour life
- 25,000 switching cycles
- 120° beam angle
- 3000K/4000K/6500K tri-colour select colour temperature
- Colour rendering index ≥80
- Not suitable for dimming
- IP65 rated for wet weather outdoor use
- Instant full light
- Plug & Play/Modular, Emergency and Sensor Sold Seperately
Energy efficient IP65 rated integrated LED round Plug & Play/Modular bulkhead suitable for surface mounting. Constructed from white tough polycarbonate with an opal diffuser. Constructed from tough corrosion resistant plastic with a white finish with opal diffuser. Plug & Play Emergency and Microwave Sensor options. Ideal for wet weather outdoor applications with IP65 rating and a IK10 impact rating. Easy to install with loop-in / loop-out connection terminal. Built-in safety isolating control gear with short circuit protection. Dimensions: Diameter Ø 325mm - Height 90mm. IP65 rated for use outdoor.
| Rated Voltage (V) | 220-240 |
| Rated Wattage (0.1W Precision) | 11/15/18 |
| Rated Total Lumens (lm) | 1300/1600/1800 |
| Beam Angle | 120 |
| Rated Life (hrs) | 50000 |
| Dimmable Type | Non-Dim |
| Colour Name | Tri-Colour Select |
| Housing colour | White |
| Glass Finish | Opal |
| Rated Voltage (V) | 220-240 |
| Rated Wattage (0.1W Precision) | 11/15/18 |
| Efficiency | 118/106/100 |
| Operating Frequency (Hz) | 50/60 |
| Operating Current (mA) | 65/85/100 (200inc. EM & Sensor) |
| Power Factor | 0.7 |
| Rated Total Lumens (lm) | 1300/1600/1800 |
| Beam Angle | 120 |
| Inrush Current (mA) | 6280 |
| Correlated Colour Temperature (K) | 3000/4000/6500 |
| Warranty (yrs) | 5 |
| Lumen Maintenance Factor | 0.96 |
| Colour Rendering Index | 80 |
| Diameter (mm) | 325 |
| Height (mm) | 90 |
| Product weight (kg) | 0.65 |
| Housing Material | Polycarbonate |
| Housing colour | White |
| IP Code | IP65 |
| IK Rating | IK10 |
| Appliance Class | II |
| Mercury Content (mg) | 0 |
| Ambient Operating Temperature (Min) | -20 |
| Ambient Operating Temperature (Max) | 45 |
| Outer Carton Quantity | 10 |
| EAN13 Barcode | 5055579317801 |
| Outer Carton GS1-128 Barcode | 02050555793178013710 |
| Certification and Marks | UKCA, CE, WEEE |
| Single Carton Width (cm) | 33.5 |
| Single Carton Length (cm) | 33.5 |
| Single Carton Height (cm) | 9.5 |
| Outer Carton Width (cm) | 345 |
| Outer Carton Length (cm) | 345 |
| Outer Carton Height (cm) | 1000 |
| Outer Carton Weight (KG) | 14.9 |
